Performance-Tested Climate Chambers

To test and validate the performance of both new and existing systems, Mobile Climate Control has invested in our own state-of-the-art climate chambers. These facilities are also available for external companies to rent and use for their testing needs.

Bob in the climate chamber-cropped with overlay

ENGINEERING SERVICES

Climate Chamber Validation for Severe-Duty Off-Road Applications

MCC climate chambers provide precise, repeatable testing of HVAC-R and thermal systems under severe-duty conditions. Built for off-road applications, they simulate extreme temperatures, humidity, and thermal loads to mirror real machine operation. This allows engineers to verify complete system performance—airflow, heating and cooling capacity, and control response—before equipment goes into the field. By identifying potential failure modes early, MCC helps OEMs lower development risk, increase reliability, and secure consistent performance in operation. Validation is used not only as a final check, but as an integrated engineering tool that supports data-driven decisions throughout the development process.

Global Locations

MCC operates a global network of climate chambers, enabling us to perform our own testing and validation of HVAC and thermal systems. We also offer these facilities for customers to rent for their own tests and validation programs. The chambers are strategically located close to key markets, and in the United States this capability is provided through our sister brand, BCC.

Norrtälje, Sweden

Click here to learn more

Vaughan, Toronto, Canada

Click here to learn more

York, Pennsylvania, USA

Click here to learn more

Climate Chamber

Norrtälje, Sweden

Temperature -30°C to +70°C / −22°F to +158°F
Humidity 15–80% RH
Sun load ~950 W/m²
Voltage 12–1000 VDC / 230–400 VAC
Vehicle capacity Up to 20 tonnes
Vehicle dimensions(LxWXH):15,4m x 4m x 4,5m
Testing scope Full vehicle & component level

Test Scenarios: Cold start, Heat-up, Cool-down, Defrost, Defog Airflow, Power consumption, Cabin CO, Noise

Learn more about this facility

Climate Chamber

Vaughan, Toronto, Canada

Temperature -40°C to +60°C / −40°F to +140°F
Humidity up to 95% RH
Sun load ~1250 W/m²
Voltage 0–1000 VDC (105 Amps) / 0 - 600 VAC (60 Amps)
Vehicle capacity Up to 20 tonnes
Vehicle dimensions (LxWXH) 21m x 7,3m x 5,5m
Testing scope Full vehicle & component level

Test Capability: Cold start, Heat-up, Cool-down, Defrost, Defog, Airflow, Power consumption, Cabin CO₂ , relative Noise, Salt fog exposure, Component thermal shock test -40C to 85C, Controlled ambient -30Cpressure cycle test 0- 600 psig, Duel or single liquid loop plate exchanger performance test

Learn more about this facility

Climate Chamber

York, Pennsylvania, USA

Temperature -40°C to +55°C / −40°F to +131°F
Humidity 20–90% RH
Sun load 7500W
Voltage 12–800 VDC / 120–480 VAC
Vehicle capacity Up to 20 tonnes
Vehicle dimensions (LxWXH): 22.4m x 5.18m x 4.5m
Testing scope Full vehicle & component level

Test Scenarios: Cold start, Heat-up, Cool-down, Defrost, Defog Airflow, Power consumption, Noise

Learn more about this facility

Rent a climate chamber!

Access MCC’s climate chambers to validate your HVAC and thermal systems under controlled, severe-duty conditions. Test full vehicle performance across temperature, humidity, and load scenarios—without investing in your own facility.

Contact us to discuss your application and request a tailored quote.
